TP-Link 28-Port Gigabit Easy Smart Switch with 24-Port PoE+, TL-SG1428PE
TP-Link 28-Port Gigabit Easy Smart Switch with 24-Port PoE+, TL-SG1428PE

TP-Link 28-Port Gigabit Easy Smart

TP-Link
OEM Verified

Product Description

TP-Link 28-Port Gigabit Easy Smart Switch with 24-Port PoE+, TL-SG1428PE

Specified at a list price of ₹16,479, the TP-Link 28-Port Gigabit Easy Smart Switch with 24-Port PoE+, TL-SG1428PE is a TP-Link industrial switch for linking PLCs, cameras and controllers on a hardened network segment. Core specifications cover interface of 24 10/100/1000Mbps RJ45 PoE+ Ports Switch with 2 SFP Slots, network protocols of IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.1q & IEEE 802.1p, power consumption of 304.7 W and voltage of 100-240 V. It is further specified with operating temperature 0-40 deg C, certification FCC, CE & RoHS, storage temperature -40 to 70 deg C and ports RJ-45. Controls engineers specify it on port count, PoE budget, DIN-rail mounting and operating temperature range. It is listed at ₹16,479 on Industrial Hardwares, supplied through verified OEMs and distributors. Bulk and project pricing for the industrial switch is quoted on request, along with current availability.

Technical Specifications

ModelTL-SG1428PE
PortsRJ-45
Weight3 kg
Voltage100-240 V
HumidityOperating: 10-90% Non-Condensing Storage: 5-90% Non-Condensing
Warranty3 Years
Interface24 10/100/1000Mbps RJ45 PoE+ Ports Switch with 2 SFP Slots
Buffer Size4.1 Mbit
CertificationFCC, CE & RoHS
Mounting typeRack Mount
Network Media10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-X MMF, SMF
Packer DetailsTP-LINK India Private Limited, Green Industrial Park, Dongri Pada, Poman, Kaman-Bhiwandi Road, Vasai East, Palghar, Maharashtra 401208
Number of Ports28
Dimensions LxWxH440x220x44 mm
Heat DissipationNo PD Connected: 92.07 BTU/h PD Connected: 1039.03 BTU/h
Importer DetailsTP-Link Corporation, South Building, No.5 Keyuan Road, Central Zone, Science & Technology Park, Nanshan, Shenzhen, P.R. China
Package Contents1 Pc Network Switch, 1 Pc Power Cord with Installation Guide, Rackmount Kit & Rubber Feet
Country of originChina
Network protocolsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.1q & IEEE 802.1p
Power Consumption304.7 W
Additional DetailsPacket Forwarding Rate : 41.7 Mbps MAC Address Table: 8K
Switching Capacity56 Gbps
Common/Generic NameNetwork Switch
Storage Temperature-40 to 70 deg C
Manufacturer DetailsTP-Link, TP-Link Corporation, South Building, No.5 Keyuan Road, Central Zone, Science & Technology Park, Nanshan, Shenzhen, P.R. China
Operating Temperature0-40 deg C

Need this integrated into a custom solution?

Tell us your use case →

Pricing

Listed Price

₹16,479

Contact OEM for bulk pricing & discounts
