TP-Link 16 Port Gigabit Desktop Switch, TL-SG116

TP-Link 16 Port Gigabit Desktop Switch, TL-SG116 from TP-Link is a industrial switch specified for linking PLCs, cameras and controllers on a hardened network segment. On the specification sheet interface of 16 x 10/100/1000Mbps Ports (Auto-Negotiation, Auto-MDI/MDIX), network protocols of IEEE 802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3x, IEEE802.1p, operating temperature of 0-40 deg C (32-104 deg F) and certification of FCC ,RoHS. Additional details cover storage temperature -40 to 70 deg C (-40 to 158 deg F), number of ports 16, dimensions 286x112x25 mm and dimensions lxwxh 286x112x25 mm. Network teams choose it where a commercial-grade switch would not survive the cabinet. It is listed at ₹9,032 on Industrial Hardwares, supplied through verified OEMs and distributors. Full specifications, current availability and bulk pricing for the industrial switch are listed above — request a quote to get a delivered price for your quantity.

Technical Specifications

EAN6.94E+12
Power10 W
Weight174 g
Humidity10-90%, Non-Condensing
Warranty3 Years
Interface16 x 10/100/1000Mbps Ports (Auto-Negotiation, Auto-MDI/MDIX)
Item CodeTL-SG116
Dimensions286x112x25 mm
Power SupplyExternal Power Adapter 100-240 VAC(Output: 12VDC / 1.0A)
CertificationFCC ,RoHS
Packer DetailsTP-LINK India Private Limited, Green Industrial Park, Dongri Pada, Poman, Kaman-Bhiwandi Road, Vasai East, Palghar, Maharashtra 401208
Number of Ports16
Dimensions LxWxH286x112x25 mm
Heat Dissipation34.1 BTU/h
Importer DetailsTP-Link Corporation, South Building, No.5 Keyuan Road, Central Zone, Science & Technology Park, Nanshan, Shenzhen, P.R. China
Package Contents16-Port 10/100/1000Mbps Desktop Switch, Power Adapter, Installation Guide, Rubber Feet
Country of originChina
Network protocolsIEEE 802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3x, IEEE802.1p
Additional DetailsLink/Act indicators per port built into each RJ-45 port System Power LED Indicators Packet Forwarding Rate: 23.8 Mpps MAC Address Table: 8 K Packet Buffer Memory: 4.1 Mb Jumbo Frame: 10 KB Green Technology 802.3x Flow Control 802.1p/DSCP QoS IGMP Snooping
Common/Generic NameSwitch
Storage Temperature-40 to 70 deg C (-40 to 158 deg F)
Customer Care Number1800 209 4168 & Email Id: support.in@tp-link.com
Manufacturer DetailsTP-Link, TP-Link Corporation, South Building, No.5 Keyuan Road, Central Zone, Science & Technology Park, Nanshan, Shenzhen, P.R. China
Operating Temperature0-40 deg C (32-104 deg F)

Need this integrated into a custom solution?

Tell us your use case →

Pricing

Listed Price

₹9,032

Contact OEM for bulk pricing & discounts
