Realtime RF-10 Proximity Card Reader
Realtime RF-10 Proximity Card Reader

Realtime RF-10 Proximity Card Reade

Realtime
OEM Verified

Product Description

Realtime RF-10 Proximity Card Reader

The Realtime RF-10 Proximity Card Reader is a Realtime access control unit built for multi-door installations where every entry event has to be logged. The unit is specified with speed of Response Speed: >0.2 Sec, frequency of 12 KHz, range of Proximity Range: 2-15 cm and technology of Wiegand: 26 Bits 34 Bits ABA Standard Format Data Output. Additional details cover dimensions lxwxh 78x44x16 mm, weight 200 g, warranty details 1 Year and model RF-10. Integrators use it where door hardware, readers and the software stack have to interoperate cleanly. It is listed at ₹1,348 on Industrial Hardwares, supplied through verified OEMs and distributors. Full specifications, current availability and bulk pricing for the access control unit are listed above — request a quote to get a delivered price for your quantity.

Technical Specifications

ModelRF-10
RangeProximity Range: 2-15 cm
SpeedResponse Speed: >0.2 Sec
Weight200 g
CurrentWorking: 70mA
DistanceCommunication Distance: 100 m Proximity Time Distance: >0.5 Sec
Frequency12 KHz
TechnologyWiegand: 26 Bits 34 Bits ABA Standard Format Data Output
Power Supply12 V DC
Number of LED2 (Red, Green)
Indicator TypeSound: Buzzer (Built in Loudspeaker)
Packer DetailsRealtime Biometrics Pvt Ltd, C-83, Ganesh Nagar Pandav Nagar complex Delhi-110092
Ambient Humidity10-90%
Dimensions LxWxH78x44x16 mm
Warranty Details1 Year
Country of originIndia
Ambient Temperature-25 to 75 Deg C
Common/Generic NameCard Reader
Customer Care Number8860 8860 86
Manufacturer DetailsRealtime Biometrics Pvt Ltd, C-83, Ganesh Nagar Pandav Nagar complex Delhi-110092

Need this integrated into a custom solution?

Tell us your use case →

Pricing

Listed Price

₹1,348

Contact OEM for bulk pricing & discounts

View OEM Profile
