Omron Rfid System Tag Batteryless Type, V680-D1KP52M-BT11
Omron Rfid System Tag Batteryless Type, V680-D1KP52M-BT11

Omron Rfid System Tag Batteryless

Omron
OEM Verified
Rfid System Tag Batteryless Type

Product Description

Omron Rfid System Tag Batteryless Type, V680-D1KP52M-BT11

Rated at a list price of ₹1,76,999, this Omron access control unit — the Omron Rfid System Tag Batteryless Type, V680-D1KP52M-BT11 — is built for multi-door installations where every entry event has to be logged. Core specifications cover protection class of IP68 (IEC60529 standard), oil resistant IP67G equivalent (JIS C 0920: 2003 Annex 1), memory capacity of 1000 bytes (user area), storage temperature of ℃ (Data retention) -40 to 125 ℃ (no freezing) and type of Memory / EEPROM. The datasheet also lists mass (g) About 10, model no V680-D1KP52M-BT11, shape (mm) M8x12 and monotaro id 46381876. Admin and security teams pick it when door events must reconcile with HR and visitor logs. It is listed at ₹1,76,999 on Industrial Hardwares, supplied through verified OEMs and distributors. Compare the access control unit against similar models on this site, then request a quote for volume pricing and lead time.

Technical Specifications

TypeMemory / EEPROM
Mass (g)About 10
Model NoV680-D1KP52M-BT11
Shape (mm)M8x12
Monotaro ID46381876
Is ConsumableN
Data Retention10 years (85 ℃ or less) /0.5 years ( to 125 ℃) after writing data
Import CountryDirect Import from Japan
Memory Capacity1000 bytes (user area)
Type of ProductRfid System Tag Batteryless Type
Compatible MetalBolt mounting
Protection ClassIP68 (IEC60529 standard), oil resistant IP67G equivalent (JIS C 0920: 2003 Annex 1)
Country of OriginJapan
No. of RewritingsData / 100,000 times per block (25°C)
Storage Temperature℃ (Data retention) -40 to 125 ℃ (no freezing)
Vibration Resistance10 to 2000 Hz , double amplitude 1.5mm, acceleration 150 m/s² , 10 sweeps for 15 minutes each in XYZ directions, no abnormalities
Direct Import from JapanTRUE
Shock Resistance (m/s²)Apply 500 impacts in each direction of X, Y, Z 3 times each 18 times in total
Operating Ambient Humidity35 to 95 % RH (no condensation)
Operation Ambient Temperature (°C)During Communication: -25 to 85 (no freezing)
Name of Manufacturer/Packer/ImporterOmron Corporation
