Omron Rfid System Tag Batteryless Type, V680-D2KF52M-BT11
Omron Rfid System Tag Batteryless Type, V680-D2KF52M-BT11

Omron Rfid System Tag Batteryless

Omron
OEM Verified
Rfid System Tag Batteryless Type

Product Description

Omron Rfid System Tag Batteryless Type, V680-D2KF52M-BT11

With a list price of ₹2,00,599, the Omron Rfid System Tag Batteryless Type, V680-D2KF52M-BT11 covers shift-based door access tied into attendance and visitor records. On the specification sheet protection class of IP67 (IEC60529 standard), oil resistant IP67G equivalent (JIS C 0920: 2003 Annex 1), memory capacity of 2000 bytes (user area), storage temperature of ℃ (Data retention) -40 to 85 ℃ (no freezing) and type of Memory / FRAM. Additional details cover mass (g) About 10, model no V680-D2KF52M-BT11, shape (mm) M8x12 and monotaro id 46381903. Integrators use it where door hardware, readers and the software stack have to interoperate cleanly. It is listed at ₹2,00,599 on Industrial Hardwares, supplied through verified OEMs and distributors. Full specifications, current availability and bulk pricing for the access control unit are listed above — request a quote to get a delivered price for your quantity.

Technical Specifications

TypeMemory / FRAM
Mass (g)About 10
Model NoV680-D2KF52M-BT11
Shape (mm)M8x12
Monotaro ID46381903
Is ConsumableN
Data Retention10 years (55 ° C or less) /2.9 years ( to 85 ° C) after writing data
Import CountryDirect Import from Japan
Memory Capacity2000 bytes (user area)
Type of ProductRfid System Tag Batteryless Type
Compatible MetalBolt mounting
Protection ClassIP67 (IEC60529 standard), oil resistant IP67G equivalent (JIS C 0920: 2003 Annex 1)
Country of OriginJapan
No. of RewritingsData / 100,000 times per block (25°C)
Storage Temperature℃ (Data retention) -40 to 85 ℃ (no freezing)
Vibration Resistance10 to 2000 Hz , double amplitude 1.5mm, acceleration 150 m/s² , 10 sweeps for 15 minutes each in XYZ directions, no abnormalities
Direct Import from JapanTRUE
Shock Resistance (m/s²)Apply 500 impacts in each direction of X, Y, Z 3 times each 18 times in total
Operating Ambient Humidity35 to 95% RH
Operation Ambient Temperature (°C)-25 to 85 (no freezing)
Name of Manufacturer/Packer/ImporterOmron Corporation
