Omron RFID System Handy Reader/Writer, V680-CH1D-PSI
Omron RFID System Handy Reader/Writer, V680-CH1D-PSI

Omron RFID System Handy Reader/Writ

Omron
OEM Verified
RFID System Handy Reader/Writer

Product Description

Omron RFID System Handy Reader/Writer, V680-CH1D-PSI

Omron offers the Omron RFID System Handy Reader/Writer, V680-CH1D-PSI as a RFID reader intended for asset and tool tracking across plants, yards and stores. Published specifications list communication protocol of RS232C (DDUB 9 pin), withstand voltage of Between connector and case / 1000 VAC 50/60 Hz 1 min Leakage current 1 mA or less, power supply voltage of DC5 ± 5% (on product connector) and protection class of IP63 (IEC standard 60529) (excluding connector). The datasheet also lists storage temperature 25～+65℃, weight Approx. 120 g (with cable and connector), type Handy terminal connection type manufactured by Scion Techlogics and model no V680-CH1D-PSI. Automation teams specify it on read range, tag population handling and how cleanly it integrates upstream. It is listed at ₹1,13,279 on Industrial Hardwares, supplied through verified OEMs and distributors. Compare the RFID reader against similar models on this site, then request a quote for volume pricing and lead time.

Technical Specifications

TypeHandy terminal connection type manufactured by Scion Techlogics
WeightApprox. 120 g (with cable and connector)
Model NoV680-CH1D-PSI
Monotaro ID39100056
Cable Length0.8 mm
Case MaterialABS resin
Is ConsumableN
Cable MaterialPVC
Import CountryDirect Import from Japan
Type of ProductRFID System Handy Reader/Writer
Protection ClassIP63 (IEC standard 60529) (excluding connector)
Shock Resistance150 ms² (3 times each in X, Y, Z directions)
Country of OriginJAPAN
Withstand VoltageBetween connector and case / 1000 VAC 50/60 Hz 1 min Leakage current 1 mA or less
Current Consumption500 mA or less (power supply voltage 5.0 V)
Storage Temperature25～+65℃
Power Supply VoltageDC5 ± 5% (on product connector)
Vibration Resistance10 to 150Hz, double amplitude 0.2mm, acceleration 15mm / s, <sup>2</sup> sweeps, up / down, left / right, front / rear, 6 sweeps, 1 sweep, 8min, 10 sweep
Insulation ResistanceBetween connectors and case / 50 MΩ or more (at 500 VDC)
Communication ProtocolRS232C (DDUB 9 pin)
Ambient Humidity to Use35 to 85% RH (no condensation)
Direct Import from JapanTRUE
Operation Ambient Temperature0～+40℃
Name of Manufacturer/Packer/ImporterOmron Corporation

Need this integrated into a custom solution?

Tell us your use case →

Use Cases

1

RFID System Handy Reader/Writer

Pricing

Listed Price

₹1,13,279

Contact OEM for bulk pricing & discounts

View OEM Profile
