Hikvision 4 Port Fast Ethernet Unmanaged PoE Switch with RJ45 Port, DS-3E0105P-E/M
Hikvision 4 Port Fast Ethernet Unmanaged PoE Switch with RJ45 Port, DS-3E0105P-E/M

Hikvision 4 Port Fast Ethernet

Hikvision
OEM Verified

Product Description

Hikvision 4 Port Fast Ethernet Unmanaged PoE Switch with RJ45 Port, DS-3E0105P-E/M

Standards PoE: IEEE 802.3af & IEEE 802.3at and a list price of ₹2,018: the Hikvision 4 Port Fast Ethernet Unmanaged PoE Switch with RJ45 Port, DS-3E0105P-E/M is Hikvision's industrial switch for shop-floor and control-cabinet networking in plants and substations. On the specification sheet standards of PoE: IEEE 802.3af & IEEE 802.3at, power consumption of 38 W, voltage of 48 V DC and operating temperature of -10 to 55 deg C. Supporting specifications include storage temperature -40 to 85 deg C, ports 4x10/100 Mbps PoE & 1x10/100 Mbps RJ45, number of ports 5 and dimensions 105x27.6x83.1 mm. Network teams choose it where a commercial-grade switch would not survive the cabinet. It is listed at ₹2,018 on Industrial Hardwares, supplied through verified OEMs and distributors. Request a quote on the industrial switch to confirm stock, delivery timelines and pricing for your order quantity.

Technical Specifications

Ports4x10/100 Mbps PoE & 1x10/100 Mbps RJ45
Weight0.2 kg
Current0.8 Amp
Voltage48 V DC
HumidityRelative: 5-95% RH (Non-condensing) Operating: 5-95% RH (Non-condensing)
Warranty3 Years
Item CodeDS-3E0105P-E/M
StandardsPoE: IEEE 802.3af & IEEE 802.3at
Dimensions105x27.6x83.1 mm
Mounting typeDesk & Wall Mounted
Packer DetailsHikvision - 1st And 2nd Floor 111 And 112, Dsidc Shed, Pocket C, Okhla Phase I, Okhla Industrial Estate, New Delhi, Delhi 110020
Shell MaterialMetal
Number of Ports5
Dimensions LxWxH105x27.6x83.1 mm
Country of originIndia
Power Consumption38 W
Additional DetailsSurge Protection: 6 kV PoE Power Budget: 35 W Max. PoE Port Power: 30 W Packet Forwarding Rate: 0.74 Mpps
Switching Capacity1 Gbps
Common/Generic NamePOE Switch
Storage Temperature-40 to 85 deg C
Manufacturer DetailsHikvision - 1st And 2nd Floor 111 And 112, Dsidc Shed, Pocket C, Okhla Phase I, Okhla Industrial Estate, New Delhi, Delhi 110020
Operating Temperature-10 to 55 deg C
